113EVK
4 flute end mill with variable helix and unequal flute spacing for roughing and finishing for heavy material removal
113EVK
Diameter of cutting edge
Corner Radius
Cutting length
Neck Relief Length
Overall Length
Products :
| D e8 | d h5 | L | l | l1 | a | Cr/r | Z | Shank ref. |
Coatings (Balinit®) |
Code | Order | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4,00 | 6,00 | 57 | 6,00 | — | — | — | 4 | HA | Alcrona | HMG113040EVK | ||
| 5,00 | 6,00 | 57 | 7,50 | — | — | — | 4 | HA | Alcrona | HMG113050EVK | ||
| 8,00 | 8,00 | 63 | 12,00 | 24,0 | 0,15 | — | 4 | HA | Alcrona | HMG113080EVK | ||
| 10,00 | 10,00 | 72 | 15,00 | 30,0 | 0,15 | — | 4 | HA | Alcrona | HMG113100EVK | ||
| 12,00 | 12,00 | 83 | 18,00 | 36,0 | 0,20 | — | 4 | HA | Alcrona | HMG113120EVK | ||
| 16,00 | 16,00 | 92 | 24,00 | 42,0 | 0,20 | — | 4 | HA | Alcrona | HMG113160EVK | ||
| 20,00 | 20,00 | 104 | 30,00 | 52,0 | 0,20 | — | 4 | HA | Alcrona | HMG113200EVK | ||
| 6,00 | 6,00 | 57 | 9,00 | 18,0 | 0,15 | — | 4 | HA | Alcrona | HMG113060EVK | ||
| 6,00 | 6,00 | 57 | 9,00 | 18,0 | 0,15 | 0,50 | 4 | HA | Alcrona | HMG113060EVK05 | ||
| 8,00 | 8,00 | 63 | 12,00 | 24,0 | 0,15 | 0,50 | 4 | HA | Alcrona | HMG113080EVK05 | ||
| 10,00 | 10,00 | 72 | 15,00 | 30,0 | 0,15 | 1,00 | 4 | HA | Alcrona | HMG113100EVK10 | ||
| 12,00 | 12,00 | 83 | 18,00 | 36,0 | 0,20 | 1,00 | 4 | HA | Alcrona | HMG113120EVK10 | ||
| 16,00 | 16,00 | 92 | 24,00 | 42,0 | 0,20 | 1,00 | 4 | HA | Alcrona | HMG113160EVK10 | ||
| 20,00 | 20,00 | 104 | 30,00 | 52,0 | 0,20 | 1,00 | 4 | HA | Alcrona | HMG113200EVK10 |
Brochure
Request information
If you have any doubts, need a guide in choosing or simply want to have more information about this tool, please contact us.
