075F
Ball nose end mill, regular version
SIL
NIG
075F
Diameter of cutting edge
Corner Radius
Cutting length
Neck Relief Length
Overall Length
Products :
| D k12 | d | L | l | l1 | Cr/r | Z | Shank ref. |
Coatings (Balinit®) |
Code | Order | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 16,00 | 17,78 | 117 | 32,00 | — | 8,00 | 4 | FORMC | Uncoated | SIL075F16 | ||
| 20,00 | 17,78 | 123 | 38,00 | — | 10,00 | 4 | FORMC | Uncoated | SIL075F20 | ||
| 25,00 | 23,83 | 147 | 45,00 | — | 12,50 | 6 | FORMC | Uncoated | SIL075F25 | ||
| 28,00 | 23,83 | 147 | 45,00 | — | 14,00 | 6 | FORMC | Uncoated | SIL075F28 | ||
| 30,00 | 23,83 | 147 | 45,00 | — | 15,00 | 6 | FORMC | Uncoated | SIL075F30 | ||
| 32,00 | 23,83 | 155 | 53,00 | — | 16,00 | 6 | FORMC | Uncoated | SIL075F32 | ||
| 36,00 | 31,27 | 178 | 53,00 | — | 18,00 | 6 | FORMC | Uncoated | SIL075F36 | ||
| 40,00 | 31,27 | 188 | 63,00 | — | 20,00 | 6 | FORMC | Uncoated | SIL075F40 | ||
| 50,00 | 44,40 | 233 | 75,00 | — | 25,00 | 6 | FORMC | Uncoated | SIL075F50 | ||
| 16,00 | 17,78 | 117 | 32,00 | 16,0 | 8,00 | 4 | FORMC | Alcrona | NIG075F16 | ||
| 20,00 | 17,78 | 123 | 38,00 | — | 10,00 | 4 | FORMC | Alcrona | NIG075F20 | ||
| 25,00 | 23,83 | 147 | 45,00 | — | 12,50 | 6 | FORMC | Alcrona | NIG075F25 | ||
| 32,00 | 23,83 | 155 | 53,00 | 16,0 | 16,00 | 6 | FORMC | Alcrona | NIG075F32 | ||
| 36,00 | 31,27 | 178 | 53,00 | — | 18,00 | 6 | FORMC | Alcrona | NIG075F36 | ||
| 40,00 | 31,27 | 188 | 63,00 | — | 20,00 | 6 | FORMC | Alcrona | NIG075F40 |
